25mm 384x288 50Hz USB Infrared Thermal Night Scope Night Vision Monocular
Introduction
This product is an outdoor thermal imaging telescope, with an advanced uncooled focal plane infrared detector and high-quality optical lens as the core, combined with a convenient and quick operating system, a compact design, and a fully functional expansion spare part. Long battery life, sturdy and durable, and suitable for various environments. It has created an ideal temperature measurement tool for users with "clear imaging, accurate measurement, simple operation and easy to carry". It is the best tool for on-site inspection, preventive maintenance and other applications. Best choice. This product is used in wild animal observation, search and rescue, police law enforcement investigation, night patrol, outdoor sports, personal security, etc. This product has a camera function, which can be connected to a computer via USB to browse the photos taken, which is convenient for multiple people to observe at the same time, creating possibilities for more applications.
Data sheet
| Probe Type | Uncooled focal plane |
| Resolution Ratio | 384×288 infrared focal plane |
| LCD Resolution | 720×540 |
| Focus Length | 19mm, 25mm, 35mm |
| Eyepiece | Single eyepiece display (the dioptric compensation is adjustable) |
| Field Angle | 19.5°×14.7°, 14.9°×11.2°, 10.7°×8° |
| Digital Zoom | 2X, 4X |
| Wavelength Coverage | 8μm-14μm |
| Frame Rate of Thermal Images | 50Hz |
| Color Palette | Rainbow/ Hot metal/ White heat/ Black heat |
| Focusing Mode | Adjustable |
| Image Storage | BMP |
| Battery | Built-in rechargeable batteries |
| USB | Micro USB |
| Operating Time | ≥4 hours |
| Operating Temperature | 0℃-45℃ |
| Storage Temperature | -20℃-60℃ |
| Weight | 400g (Optional upgraded version is 541.2g, with laser light) |
| Size | 186mm x 69mm x 68mm (Optional upgraded version:187.3mm x 68mm x 68.2mm) |
Structure
Q: Who are you?
A: We are a thermal camera module manufacturer,who is special with
uncooled thermal camera module and cooling thermal module product
and related product.
Q: How long is your delivery time?
A: Generally uncooled thermal module it is 4-5 weeks after
deposit,cooling thermal module it is 3-4 mouths adter deposit.
Q: Do you provide samples ?
A: No, we provide a complete solution.
Q: Can you do customized product?
A: Yes, we do.
Q: What is your terms of payment ?
A: T/T, L/C, etc.
Q. Do you provide warranty for your products?
A: Yes, we promise one year warranty for all our products.
Q.What is your method of payment?
A: Pay via T/T, Western Union, Paypal, Escrow is welcome.
Q.What is Minimum Order Quantity?
A: Sample order is welcome, but the price is depend on the
quantity.
Q: How to ship the goods?
A: For small parcels, we recommend to use the express, such as
Fedex, DHL, TNT, UPS etc.
For big order, we also have cooperated forwarders.
Q:Compare to other companies, what superiorities do you have?
A: We have independent core technology of thermal imaging, we are
specialized at manufacturing thermal camera & system solution. We
devote to thermal module field and related technology to supply
best products & service to customers worldwide.
Q: Do you accept OEM/ODM?
A: Yes! If you have OEM or ODM plans , highly welcome to negotiate
with our sales person, we can provide you guaranteed products, and
pretty competitive prices.
Q: Where is your loading port?
A: Shanghai; ningbo,shenzhen
|
|
