Professional Optoelectronic Products Manufacturer
7 Years
| Ask Lasest Price | |
| Brand Name : | |
| Model Number : | A6417S |
| Supply Ability : | 500/Month |
| Price : | Negotiation |
| Payment Terms : | All are acceptable except L/C |
| Delivery Time : | 3-5days |
With the advantage of small size, light weight; rich function, easy
to extend; standard interface , the system is stable and reliable,
easy for further integration and development.
| Performance | |
| FOV/Minimum Focus Distance | 31° x25°/1m(19mm) |
| N.E.T.D | ≤45mK@30°C, #F1.0 |
| Detector Type | Uncooled microthermal VOx FPA |
| Resolution | 640X512 |
| Wave range | 8-14um |
| Spatial resolution | 0.89mrad(19mm Lens) |
| Environment | |
| Operating Temperature | -40°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humility | 95% Non-condensing |
| Protection Rate | Customize |
| Physical | |
| Weight | ≤100g, Without Lens |
| Size | ≤40mm(W)x40mm(H)x48mm(L), Without Lens |
| Interface & Electronics | |
| Interface | J30J-9(default),Mini CameraLink(Customize) |
| Power Supply | DC 3-10V |
| Video Output | Combined:PAL@50Hz(NTSC@60Hz customize) |
| Digital Output | CameraLink Customize |
| Control | RS232(default),RS485, RS422(Customize) |
| Power Consumption | ≤2.0W(Static) |
| Start Up Time | ≤20s |
| Optional Accessories | |
| Lenses | 13mm: 45° x 37° |
| DRI [Human: 1.7m x 0.6m] | |
| Detect | 400m |
| Recognize | 200m |
| Verify | 100m |
